30S LiFePO4 Li-ion smart bms pcm with android Bluetooth app UART bms wi software (APP) monitor
- Product Model：BMS-30S005
- Can Customized: 20S-30S
- Continuous Current: 40A-100A
- Soft ware: External UART RS232
- Product description：UART to USB module or to Bluetooth should use together with the board. 1.UART RS232 to USB module connect to PC by USB. 2.Bluetooth module can connect to smart phone, support android 4.3 abo
Main Features :
1)Smart BMS with app or PC module;
2) Balance & Balance wires attached;
3) Multi Temperature switches;
4) MOS transistor can control the battery charge and discharge;
5) low standby current consumption.
6) With UART interface, can support PC or smart phone.
7) Over charge and over discharge can set by software APP (Android version).
8) Welcome OEM
Adjustable Parameters:
1.Balance voltage setup: Balance voltage Range: 3.3-4.2V
2.Over-voltage voltage setup: Charge voltage Range : 3.6-4.3V
3.Under-voltage voltage setup: Discharge voltage Range : 2.0-3.3V
4.Over Charge/Discharge current Setup...
APP Parameters reference:
PC Parameters interface:
Li-ion test sheet:
Parameters:
